HE3TM Series 3D Linear Transfer System
for Mid-Size Press Lines
The Current-Central HE3TM Series Three-Axis Transfer System is a specialized automation solution purpose-built for single-press multi-station stamping operations, engineered to deliver high speed, precision, and flexibility for medium-sized workpieces. Its core functions cover the entire stamping transfer workflow.
Key Functions
Three-Axis Precision Transfer: Executes coordinated X/Y/Z axis motion to complete the pick-up, traverse, lift, and drop-off of stamping parts between multi-station presses, ensuring accurate and stable part positioning.
Intelligent Motion Control: Features modular programming for easy parameter editing and fast setup; auto-generates optimal motion curves between pick-up and drop-off points, eliminating complex manual programming.
Flexible Production Switching: Supports flexible recipe storage, enabling one-click product changeover in minutes to adapt to different medium-sized stamping part specifications.
Optional Automatic Tooling Change: Equipped with a fully automated gripper arm changeover function (optional), including auto connection and inspection of pneumatic/electrical joints, reducing tooling changeover time from tens of minutes to just a few.
Comprehensive Safety Protection: Integrates mechanical & electronic limiters, dual-circuit braking system, pneumatic monitoring, anti-fall cylinder protection, and safety interlocks with the press to ensure safe operation in stamping scenarios.
Stable Long-Term Operation: Built with a high-rigidity structure and precision drive components, guaranteeing repeatable accuracy and consistent performance over long production runs.
Specification of Current-Central HE3TM Series 3D Linear Transfer System for Mid-Size Stamping Line
The Current-Central HE3TM Series Three-Axis Transfer System adheres to strict industrial standards, with stable and reliable performance parameters that fully meet the requirements of sheet metal stamping automation production. Key specification parameters are as follows:
SPM Definition: Strokes Per Minute, representing the number of transfer cycles completed per minute.
Compatibility: Optimized for single-press multi-station stamping lines, compatible with mainstream press brands in the medium-sized stamping industry.
Customization: Basic models cover 100–200 kg load and 15–30 SPM speed; tailored configurations for special stroke, load, or speed requirements are available upon request.
1/5 Core Structural Components
High-Rigidity Frame: FEA-optimized cast iron + box-type structure, minimizing deformation under load and ensuring long-term dimensional stability.
Linear Guide Rails & Transmission Shafts: Precision-machined linear guides and ball screws for X/Y/Z axes, enabling smooth, low-friction motion and high positioning accuracy.
Main Parts of Current-Central HE3TM Series 3D Linear Transfer System for Mid-Size Stamping Lines
The Current-Central HE3TM Series Three-Axis Transfer System is composed of core structural, drive, control, execution, and safety components, forming a robust and reliable stamping transfer automation system:
2/5 Drive Components
Precision Servo Drives: High-performance servo motors paired with precision reducers, delivering stable torque and repeatable motion control for consistent transfer accuracy.
3/5 Control System
Intelligent Motion Controller: Core unit for three-axis coordinated motion, press synchronization, auto motion curve generation, and recipe management.
User-Friendly HMI: Intuitive interface for parameter setting, program editing, fault diagnosis, and production status monitoring, simplifying operation for on-site staff.
4/5 Execution Components
Gripper Arms & Tooling Bars: Executes the grabbing and releasing of stamping parts; supports optional automatic changeover for quick replacement of different end effectors.
End Effectors: Optional mechanical gripper, pneumatic gripper, or suction cup, adaptable to various medium-sized stamping part shapes and materials (metal sheets, structural components, etc.).
5/5 Safety & Auxiliary Components
Multi-Layer Safety Devices: Mechanical/electronic limiters, dual-circuit braking system, pneumatic monitoring sensors, anti-fall cylinders, and press safety interlocks, complying with industrial safety standards.
Diagnosis & Monitoring Modules: Real-time fault detection and alarm system, displaying error codes and solutions for quick troubleshooting.
1/7 Optimized for Medium Workpieces
Perfectly balances stroke (500–800 mm X-axis), load (100–200 kg), and speed (15–30 SPM), tailored to the needs of medium-sized stamping parts in automotive, appliance, and hardware industries.
Advantages of Current-Central HE3TM Series 3D Linear Transfer System for Mid-Size Stamping Lines
Compared with traditional stamping transfer equipment and general three-axis transfer systems, the HE3TM Series offers distinct core advantages for medium-sized stamping production:
2/7 High Rigidity & Long-Term Precision
FEA-optimized cast iron box structure and precision servo/linear guide components ensure minimal deformation under load and repeatable accuracy over extended production runs, reducing scrap rates.
3/7 Intelligent & Efficient Operation
Auto-generated motion curves eliminate complex manual programming; modular programming and recipe storage cut product changeover time to minutes, boosting production efficiency.
4/7 Optional Automatic Tooling Change
Fully automated gripper arm changeover (with pneumatic/electrical auto-connection) slashes tooling change time by up to 90%, maximizing line uptime.
5/7 Comprehensive Safety Assurance
Multi-layer mechanical/electronic safety protection and press interlocks prevent equipment damage and personal injury, ensuring safe, reliable operation 24/7.
6/7 Wide Application Adaptability
Covers 4 models with graded strokes, loads, and speeds, suitable for small-medium to large-medium stamping parts; compatible with single-press multi-station lines across automotive, appliances, hardware, and electronics.
7/7 Cost-Effective Automation
Delivers high-performance automation at a competitive cost, helping medium-sized stamping manufacturers reduce labor reliance, improve output, and enhance product consistency without excessive investment.
1/3 Application Scenarios
The HE3TM Series Three-Axis Transfer System is widely applied in key stamping manufacturing fields for medium-sized parts:
Automotive Industry: Seat frames, brake plates, and other medium structural stampings.
Home Appliances: Washing machine drums, microwave panels, air-conditioner components, and refrigerator parts.
Hardware Manufacturing: Kitchenware, hand tools, metal casings, and fasteners.
Electronics Industry: Metal shields, connector housings, and small-to-medium electronic component stampings.
More About Current-Central HE3TM Series 3D Linear Transfer System for Mid-Size Stamping Lines
2/3 Service Support
Pre-sales: Customized solution design based on customer press type, stamping part specifications, production capacity, and layout requirements.
In-sales: On-site installation, precision commissioning, and operator training to ensure the system is quickly put into stable production.
After-sales: Regular equipment maintenance, fault troubleshooting, and technical upgrade support, providing long-term reliable operation guarantee.
