HE-machine provides a flexible choice for sheet metal stamping line. In some of the small tonnage stamping that using thin material, an uncoiler, and a servo feeder machine can become a reliable and straightforward coil feeding line for the application. A precision straightener machine can also be integrated into this line if needed.

Applicable Material

• Material Thickness: under 2.0 mm

• Coil Width: 20-600 mm

Coil Line Structure

• Uncoiler Machine (passive, motorized, double head for optional)

• Coil Feeder (mechanical roll, servo roll feeder for optional)

Features

A Straightforward and Reliable Feed System

The uncoiler and coil feeder feature independent control systems and a sensor rack for loop control, enabling easy installation and operation.

Various Configuration Options

HE offers various configurations based on your material specifications. For uncoilers, two expansion types (manual and hydraulic) are available for different coil weight ranges.

For flexible metal coil materials, a hold-down arm is provided. This pneumatic device with a non-motorized PU rubber wheel applies pressure to the coil surface to prevent loop rebounding during uncoiling.

A contact sensor rack detects and controls the material loop; an induction rod is available if required. Some uncoilers are equipped with a coil car for smooth coil loading.

HE provides both high-precision and conventional straighteners to meet the straightening needs of different product stamping lines.

The HE servo feeder RNC series is the most popular option. Servo feeders with mechanical release (NCF) are also available for higher-speed requirements.

Uncoiler Machine MT/MT-F

Medium duty uncoiler MT-F as an example reference:

• Uncoiler operation: Motorized

• Uncoiler expansion: Hydraulic expansion

• Coil hold-down arm: Pneumatic type, non-motorized PU wheel

• Loop control: Sensor rack

• Operation control: Control handle with manual button

• Loading capacity: 5000kgs

• Brake system: Band brake

Main Parts & Description

Coil Feeder RNC

HE servo feeder is a reliable choice for sheet metal feeding, meeting various coil feeding requirements.

Thoughtful mechanical design ensures a highly synchronous structure, the fundamental guarantee for high-precision feeding.

Feed rolls are double-sided gear-driven with ISO 6 accuracy. Made of high-quality bearing steel, they reach HRC60 hardness.

For the electric system, leading international brand components ensure reliable control and easy maintenance. The computer control system guarantees fast, accurate performance, and HE offers multiple control systems optional to suit user habits in different countries.
